CS-6F Fire-rated Surface Speaker 6.5in - 100V

CS-6F is a fire-rated ceiling or wall speaker in a powder-coated steel enclosure that is surface-mounted through an internal cross-bar assembly. This design offers convenient and discreet public address coverage where recessed installation is not possible or may compromise a fire barrier. Internally, the 6.5" full-range driver is connected via a fire-resistant cable to a ceramic terminal block, thermal fuse, and 100V transformer. Cable access is via gland knock-out holes. Fully certified to EN54-24 for use in fire-rated commercial installations.

Features

Powder-coated steel enclosure
Removable surface-mounting bar
Ceramic terminal block and thermal fuse fitted.
Fire resistant EN54-24 compliant

Specifications

Construction — Powder-coated steel housing and grille
Driver — 165mmØ (6.5") full range woofer
Tappings — 0.75W, 1.5W, 3W, 6W
Sensitivity — 93dB (1W/1m)
Frequency response — 150Hz-20kHz
Impedance — 8 ohms
Approvals — EN54-24
Dimensions — 76 x 170mmØ
Weight — 910g
