Adastra
Line Splitter
Line Splitter
📦 Available from our UK distribution warehouse
This item is available for UK delivery but is not held at our Ashley Road shop. Please contact us before arranging collection.
Couldn't load pickup availability
Signal splitter with 2 line inputs which are buffered and divided across 6 outputs each. Can be used as a 6-way stereo splitter or can be switched as a mono system feeding all 12 outputs from input A. Applications include zone mixing, personal monitoring, effects patching and routing in complex recording setups.
Features
Up to 12 outputs from 1 or 2 inputs
Individual volume control for each output
Input peak LEDs
Specifications
Power supply — 115/230Vac, 50/60Hz (IEC)
Inputs — A & B, (6.3mm jack)
Outputs — 1 - 6 & 7 - 12 (6.3mm jack)
Input impedance — 20k Ohms
Output impedance — 220 Ohms
Frequency response — 20Hz - 20kHz, +0/-1dB
Signal to noise ratio — >95dB
THD — <0.008%
Dimensions — 483 x 44 x 170mm
Weight — 2.0kg
